Plug-in receivers

Ditec offers a complete range of receivers suitable for any use and for frequencies of 433.92 MHz and 868.35 MHz.

Guaranteed compatibility with the standard Ditec radio protocols (Dip Switch, Fixed code, Rolling code) and the new Encrypted AES 128-bit and PROTECTED mode protocols.

Thanks to the removable memory module for transmitters, compatibility is guaranteed with the ZEN MANAGER/ZENPAD system.

BIXR2 - Two-channel plug-in 433.92 MHz receiver

Two-channel 12-24 V DC receiver for plugging into a control panel or a card-holding base. Supplied with the removable BIXMR2 memory module for storing up to 200 remote controls.

Compatible with the BIXMR memory module for storing up to 1,000 remote controls.

2 relay contacts 1A / 30V (1NO, 1NO/NC)

1 configurable relay: Step by Step, Impulse, 300 s Timer with toggle, 3 s, 30 s, 90 s and 180 s Timer

Compatible with the Ditec Dip Switch, Fixed code, Rolling code, AES 128-bit Encrypted and PROTECTED mode protocols

BIXPR2 - Two-channel plug-in 868.35 MHz receiver

Two-channel 12-24 V DC receiver for plugging into a control panel or a card-holding base. Supplied with the removable BIXMR2 memory module for storing up to 200 remote controls.

Compatible with the BIXMR memory module for storing up to 1,000 remote controls.

2 relay contacts 1A / 30V (1NO, 1NO/NC)

1 configurable output: Step by Step, Impulse, 300 s Timer with toggle, 3 s, 30 s, 90 s and 180 s Timer

Compatible with the Ditec Dip Switch, Fixed code, Rolling code, AES 128-bit Encrypted and PROTECTED mode protocols

BIXLR42 - Four-channel plug-in 433.92 MHz receiver

Four-channel 12-24 V DC receiver for plugging into a control panel or a card-holding base.  Supplied with the removable BIXMR memory module for storing up to 1,000 remote controls.

Configurable output through dip-switch (3 impulsive/stepped outputs + 1 impulsive/timed output).

Compatible with the Ditec Dip Switch, Fixed code and Rolling code protocols.
